Energy Management

Smart Meter Wireless Adaptor and Smart Energy Watcher

The Smart Meter Wireless Adaptor facilitates wireless communication between utility smart meters and energy management systems, enabling real-time data transmission and eliminating manual meter reading. The Smart Energy Watcher complements the adaptor by providing users with a user-friendly interface to access and analyze energy consumption data, offering real-time information, usage trends, and personalized recommendations for efficient energy management. These innovative solutions revolutionize energy monitoring and promote sustainable practices.

Smart Meter Wireless Adaptor

Modbus RTU and Modbus TCP Convertor

Smart Meter Wireless Adaptor is a Low Form Factor pluggable module which when connected to the normal smart-meter turns it into an IoT device. It acquires all energy readings from the meter via serial communication and sends them to the remote server via cloud. These energy readings can be accessed and analysed remotely using web/mobile applications.

It can interface with Modbus RTU over RS232/RS485 ports and also Modbus TCP.

Benefits

When wireless connection is lost, data is stored internally and pushed to the cloud when connection is re-established. Aggregator will slot the delayed data in appropriate data blocks and automatically rework the aggregations as
appropriate.

Machine Utilization can be monitored through the use of wireless smart meters which constantly stream the data. It will help to identify what is the idle run time, load run time and shut down time of each machine.

Features

Wireless Communication

Have Questions? Contact Us

Smart Energy Watcher

Smart Energy Watcher is an innovative smart device embedded with digital intelligence that helps industries to monitor and manage single and three Phase power consumption. This Industrial power measuring and transmitting device has the capability to monitor and communicate with energy management application hosted in the cloud to provide real-time information and data on your energy consumption

Benefits

Equipment that are power hungry is a real worry for any organization. It is not easy to figure out where the actual consumption is that drives the overall cost high. Energy watcher gives a clear measure of the power consumption at an equipment level. In manufacturing industry, it is possible to measure the idle time, down time and the actual job handling time very clearly at a machine level thereby giving a clear picture of the machine’s overall utilization.

• Facilitates aggregation of data from disjoint sources and improveoverallsystem management and monitoring.

• Reduce Organization wide energy consumption.

• Reduce wastage by optimizing energy usage.

• Improve asset utilization.

• Optimize OPEX,CAPEX.

• Real-time analytics to aid improved decision making.

• Facilitate management to gain insights into the varying organizat ons energy usage pattern over any given period oftime.

Features

Domestic Meter - 35A, 50A
Industrial Meter -100A to 1000 A
Monitor 3 Phase power up to 100 KVA
The sensor front end has an isolation voltage of 4000V
Uses Split core CT and hence it is easy to install with zero downtime required.
Track consumption of energy/electricity for any phase for any high capacity equipment.
Machine Utilization to identify idle/load run and shutdown time. Ideal for process optimization.
Get hourly, daily, weekly and monthly consumption
User can set energy usage thresholds for their machines/ equipment
Notification/alert on your smartphone when usage goes beyond the defined thresholds
Data encrypted before transmission
Device authentication mode enabled to prove the genuineness of the device joining the network.
It can measure Voltage (RMS and Peak), Current (RMS and Peak), Active Power, apparent Power, Reactive Power and Power Factor.

Wireless Communication

Have Questions? Contact Us
